Mechanical installation
Standard devices in t he power range 3 ... 22 kW
Assembly in push-through technique (thermal separation)
5

125
EDS84ASC552 EN 10.0
StateLine, HighLine
8400GG107e
Fig. 5-29 Device dimensions
h b t h
1
h
2
b
1
t
1
t
3
g
1
g
2
[kW] [mm]
E84AVxxD7524xXx7.5
325 174 141 378 426 140 128 64 6 5
E84AVxxD1134xXx 11
E84AVxxD1534xXx 15
E84AVxxD7524xBx 7.5
325 174 161 378 426 140 148 64 6 5
E84AVxxD1134xBx 11
E84AVxxD1534xBx 15
