Mechanical installation
Standard devices in t he power range 3 ... 22 kW
Assembly in push-through technique (thermal separation)
5

127
EDS84ASC552 EN 10.0
TopLine
8400GG107f
Fig. 5-31 Device dimensions
h b t h
1
h
2
b
1
t
1
t
2
t
3
g
1
g
2
[kW] [mm]
E84AVTCD7524xXx7.5
325 174 156 378 426 140 143 182 64 6 5
E84AVTCD1134xXx 11
E84AVTCD1534xXx 15
E84AVTCD7524xBx 7.5
325 174 176 378 426 140 163 202 64 6 5
E84AVTCD1134xBx 11
E84AVTCD1534xBx 15
