Mechanical installation
Standard devices in t he power range 3 ... 22 kW
Mounting i n ”cold plate” technique
5

134
EDS84ASC552 EN 10.0
StateLine, HighLine
8400GG107b
Fig. 5-37 Device dimensions
h b t h
1
h
2
b
1
t
1
g
1
g
2
[kW] [mm]
E84AVxxC7524xXx7.5
325 174 141 378 426 140 128 6 5
E84AVxxC1134xXx 11
E84AVxxC1534xXx 15
E84AVxxC1834xXx 18.5
350 231 164 407 458 205 151 6 7
E84AVxxC2234xXx 22
E84AVxxC7524xBx 7.5
325 174 161 378 426 140 148 6 5
E84AVxxC1134xBx 11
E84AVxxC1534xBx 15
E84AVxxC1834xBx 18.5
350 231 184 407 458 205 171 6 7
E84AVxxC2234xBx 22
