Mechanical installation
Standard devices in a power range of 30 ... 45 kW
Mounting i n ”cold plate” technique
5

152
EDS84ASC552 EN 10.0
TopLine
8400GG108a
Fig. 5-48 Dimensions for mounting
d
1
d
2
d
3
c c
1
c
2
c
3
i j
11
j
21
[kW] [mm] [kg]
E84AVTCC3034xXx30
8 12 500 40 20 20 210 0 >95 > 120 16.9
E84AVTCC3734xXx 37
E84AVTCC4534xXx 45
E84AVTCC3034xBx 30
8 12 500 40 20 20 210 0 >95 > 120 17.0
E84AVTCC3734xBx 37
E84AVTCC4534xBx 45
