Electrical installation
Safety instructions for the installation according to U
L
or U
R
6
163
EDS84ASC552 EN 10.0
Warnings!
For CSA Certification drives are intended to be used with Chokes -
UL Recognized (XPTQ2/8, FOKY2/8) or CSA Certified (XPTQ2, FOKY2), File
Number E103521 or E198787, mounted on the line side of the devices.
The c hokes are listed in chapter 4.2 Rated Data and chapter 11.2 Accessories.
Alternatively - For Canadian Certification drives are intended to be used as
follows:
Transient surge suppression for 240 V models
shall be installed on the line side of this equipment and shall have met the
requirements of CSA C22.2 No. 8.
It shall be suitable for overvoltage category III.
It shall be rated
– phase to ground: 240 V,
– phase to phase: 240 V.
It shall provide protection for a rated impulse withstand voltage peak of
– line to line: 2.5 kV.
Transient surge suppression for 400/500 V models
shall be installed on the line side of this equipment and shall have met the
requirements of CSA C22.2 No. 8.
It shall be suitable for overvoltage category III.
It shall be rated
– phase to ground: 500 V,
– phase to phase: 500 V.
It shall provide protection for a rated impulse withstand voltage peak of
– line to line: 2.5 kV.
