Diag nostics
Display of operating data, diagnostics
Status display via controller LEDs
9
268
EDS84ASC552 EN 10.0
Legend
The symbols used for indicating the LED states have the following meaning:
LED flashes once approx. every 3 seconds (slow flash)
LED flashes once approx. every 1.25 seconds (flash)
LED flashes twice approx. every 1.25 seconds (d ouble flash)
LED blinks every second
LED is permanently on
