Technical data
Rated data
Operation at a rated mains voltage of 500 V
4
53
EDS84ASC552 EN 10.0
Operation with external mains choke/mains filter
Type
Installation according to EN 60204-1
1)
Installation according
to UL
2)
FI
3)
L1, L2, L3 - Laying system L1, L2, L3
B2 C F
[A] [A] [mm
2
] [mm
2
] [mm
2
] [A] [AWG] [mA]
E84AVxxx3714 C 6 6 1.0 - - 6 18
30
3)
E84AVxxx5514 C6 6 1.0 - - 6 18
E84AVxxx7514 C6 6 1.0 - - 6 18
E84AVxxx1124 C6 6 1.0 - - 10 16
30
3)
E84AVxxx1524 C6 6 1.0 - - 10 16
E84AVxxx2224 C10 10 1.5 - - 10 16
E84AVxxx3024xxS C10 10 1.5 - - 15 14 300
3)
E84AVxxx3024xx0 C10 10 1.5 - - 15 14
300
3)
E84AVxxx4024 C16 16 2.5 - - 20 12
E84AVxxx5524 C20 20 4 - - 20 12
E84AVxxx7524 C20 20 4 2.5 - 20 12
300
3)
E84AVxxx1134 C32 32 10 10 - 30 10
E84AVxxx1534 C32 32 10 10 - 40 8
E84AVxxx1834 C50 50 16 - - 40 8
300
3)
E84AVxxx2234 C63 63 25 - - 50 6
E84AVxxx3034 C80 80 - 16 - 70 4
300
3)
E84AVxxx3734 C100 100 25 - 80 4
E84AVxxx4534 C125 125 50 - 100 3 300
3)
1)
These values are recommendations only. Other dimensioning values/laying systems are possible (e.g. according to
VDE 0298-4). The cable cross-sections apply under the following conditions: Use of PVC-insulated copper cables,
conductor temperature < 70 °C, ambient temperature < 45°C, no bundling of cables or cores, three loaded cores.
2)
Use UL-approved cables, fuses and fuse holders only.
UL fuse: voltage 500 V, tripping characteristic for example ”H”, ”K5” or ”CC”. The cable cross-sections apply under
the following conditions: conductor temperature < 75 °C, ambient temperature < 45°C.
3)
Universal-current sensitive earth-leakage circuit breaker, short-time delay
If cables are longer than 50 m, the protective circuit-breaker may respond, depending on the cable type and
switching frequency.
Circuit breaker
Fuse of gG/gL utilisation category or semiconductor fuses of gRL utilisation category
Fuse
Observe national and regional regulations
