Technical data
Rated data
Operation with increased power at a 400 V mains
4

58
EDS84ASC552 EN 10.0
Mains current at I
aN
Apparent output power Motor power
with external
mains choke
without external
mains choke
U, V, W 4pol.ASM
Type I
LR
[A] I
LR
[A] S
aR
[kVA] P
aR
[kW]
E84AVxxx3714 1.7 2.2 1.0 0.55
E84AVxxx5514 2.4 2.9 1.4 0.75
E84AVxxx7514 2.9 - 1.8 1.1
E84AVxxx1124 3.8 5.3 2.4 1.5
E84AVxxx1524 4.7 6.6 3.0 2.2
E84AVxxx2224 6.1 - 4.2 3.0
E84AVxxx3024xxS 8.4 - 5.5 4.0
E84AVxxx3024xx0 8.4 11.8 5.5 4.0
E84AVxxx4024 10.6 15.7 7.2 5.5
E84AVxxx5524 18.0 - 9.7 7.5
E84AVxxx7524 21.0 28 13.1 11
E84AVxxx1134 29.0 - 17.6 15
E84AVxxx1534
1)
- - - -
E84AVxxx1834 42.2 - 29.2 22
E84AVxxx2234
1)
50.8 - 35.2 30
E84AVxxx3034
1)
66.0 - 45.6 37
E84AVxxx3734
1)
81.6 - 56.9 45
E84AVxxx4534
1)
96.0 - 66.6 55
1)
only with external mains choke
Assignment of external mains chokes
Assignment
Type Mains choke required Mains choke
E84AVxxx3714 No EZAELN3002B153
E84AVxxx5514 No
EZAELN3004B742
E84AVxxx7514 Yes
E84AVxxx1124 No
E84AVxxx1524 No EZAELN3006B492
E84AVxxx2224 Yes EZAELN3008B372
E84AVxxx3024xxS Yes EZAELN3010B292
E84AVxxx3024xx0 No EZAELN3010B292
E84AVxxx4024 No EZAELN3016B182
E84AVxxx5524 Yes EZAELN3020B152
E84AVxxx7524 No EZAELN3025B122
E84AVxxx1134 Yes EZAELN3030B982
E84AVxxx1534 - -
E84AVxxx1834 Yes EZAELN3045B651
E84AVxxx2234 Yes EZAELN3063B471
E84AVxxx3034 Yes EZAELN3080B371
E84AVxxx3734 Yes EZAELN3090B331
E84AVxxx4534 Yes EZAELN3100B301
