Technical data
Current characteristics
4
68
EDS84ASC552 EN 10.0
The maximum output currents depending on the mains voltage and the switching
frequency modes are shown in the following tables.
Maximum output currents [A]
1)
at a fixed switching frequency and U
LN
= 230V
2kHz 4kHz 8kHz 16 kHz
Type I
aM02
I
aM2
I
aM04
I
aM4
I
aM08
I
aM8
I
aM016
I
aM16
E84AVxxx2512 3.4 3.4 3.4 3.4 3.0 3.4 2.3 2.8
E84AVxxx3712 4.8 4.8 4.8 4.8 4.2 4.8 3.2 4.0
E84AVxxx5512 6.0 6.0 6.0 6.0 4.1 6.0 2.9 5.0
E84AVxxx7512 8.0 8.0 8.0 8.0 5.4 8.0 3.8 6.6
E84AVxxx1122 8.3 11.0 8.3 11.0 7.4 11.0 4.1 9.1
E84AVxxx1522 10.5 14.0 10.5 14.0 9.5 14.0 5.3 11.6
E84AVxxx2222 14.3 19.0 14.3 19.0 12.8 19.0 7.1 15.7
