Technical data
Current characteristics
4
70
EDS84ASC552 EN 10.0
Maximum output currents [A]
1)
at a variable switching frequency
U
Lr
= 230V
Type I
aM0v
I
aMv
E84AVxxx2512 3.4 3.4
E84AVxxx3712 4.8 4.8
E84AVxxx5512 6.0 6.0
E84AVxxx7512 8.0 8.0
E84AVxxx1122 8.3 11.0
E84AVxxx1522 10.5 14.0
E84AVxxx2222 14.3 19.0
Maximum output currents [A]
1)
at a variable switching frequency
U
Lr
= 400V/U
Lr
= 500V
Type I
aM0v
I
aMv
E84AVxxx3714 2.6 2.6
E84AVxxx5514 3.6 3.6
E84AVxxx7514 4.8 4.8
E84AVxxx1124 4.8 6.4
E84AVxxx1524 5.9 7.8
E84AVxxx2224 8.4 11.2
E84AVxxx3024xxS 11.0 14.6
E84AVxxx3024xx0 11.0 14.6
E84AVxxx4024 14.3 19.0
E84AVxxx5524 19.5 26.0
E84AVxxx7524 24.8 33.0
E84AVxxx1134 35.3 47.0
E84AVxxx1534 48.0 64.0
E84AVxxx1834 58.5 78.0
E84AVxxx2234 70.5 89.3
E84AVxxx3034 88.5 112.1
E84AVxxx3734 108.0 136.8
E84AVxxx4534 133.5 169.1
1)
The shown values apply to the operation with ambient temperatures of up to +45°C for 2/4kHz and up to +40°C for
8/16kHz. For ambient temp eratures between +40/45°C and +55°C, a derating from 2.5 %/K to the given values must
be observed.
