Technical data
TopLine C control terminals
Multi-encoder c onnection
4

86
EDS84ASC552 EN 10.0
X8 Pin
Description
EYF001... cable EYF002...
cable
EYDxxxxAxxxxS10S09
cable
TTL 1V
SS
1V
SS
Hiperface
SSI DFIn DFOut
1 A A COS
n. c.
A -
2 GND GND GND GND GND -
3 B B Sin
n. c.
B -
4 V
CC
V
CC
V
CC
U
S
V
CC
-
5 Z Z +RS485 Data + Z -
6
n. c. n. c. n. c. n. c.
n. c. -
7 -KTY -KTY -KTY
n. c.
- A
8
n. c. n. c. n. c.
Clock + - Z
9 /A /A Ref COS
n. c.
A -
10
n. c. n. c. n. c. n. c.
- B
11 /B /B Ref SIN
n. c.
B -
12
n. c. n. c. n. c. n. c.
- B
13 /Z /Z -RS485 Data - Z -
14 +KTY +KTY +KTY
n. c.
- A
9400SSP000X8
15
n. c. n. c. n. c.
Clock - - Z
Setting the supply voltage
The s upply voltage of the encoder must be adjusted depending on the cable length.
This value is adjusted via the ”Encoder voltage” parameter, C00421.
Encoder U
r
Voltage setting [V] in C00421 for cable length [m]
Product key [V] 0-10 10 - 30 30 - 50 50 - 70 70 - 90 90 - 100 100 -150
TTL
IG2048-5V-T
5 ±5% 5.0 5.0 5.1 5.1 5.2 5.2 5.3
IG4096-5V-T
IK2048-5V-T
IK4096-5V-T
Sin/cos
IG1024-5V-V
5 ±5% 5.0 5.0 5.1 5.1 5.2 5.2 5.3
IG2048-5V-S
Sin/cos (Hiperface)
AM1024-8V-H
8
(7 ... 12)
8.0
Tab. 4-1
V
r
Rated voltage of the encoder
The values provided in Tab. 4-1 apply if Lenze system cables are used at typical ambient
temperatures.
Different cables, cable cross-sections, or extreme ambient temperatures may require
adaptation after another metrological measurement process.
Encoders (e.g. laser-based length measuring systems) must be externally supplied if their
supply m ust be increased.
