6.1.3 USB connections
The USB interfaces are used for connecting peripherals with USB connection.
These interfaces comply with the USB 2.0 or USB 3.0 standard requirements.
USB 2.0
Pin number Signal name
1 V
2 D -
3 D +
4 GND
USB 3.0
Pin number Signal name
1 VBUS
2 D -
3 D +
4 GND
5 StdA_SSRX−
6 StdA_SSRX+
7 GND_DRAIN
8 StdA_SSTX−
9 StdA_SSTX+
