6.1.4 Network connection (RJ45)
If the drivers required for functioning are installed on the device, the control system may be
integrated in an Ethernet network supporting the 1 Gbit/s standard by using the Ethernet
10/100/1000 BaseT network connector. The specifications of this network topology must be
observed.
10/100Mbit/s
Pin number Signal name
1 TX +
2 TX -
3 RX +
4 NC
5 NC
6 RX -
7 NC
8 NC
1000 Mbit/s
Pin number Signal name
1 D1+
2 D1-
3 D2+
4 D3+
5 D3-
6 D2-
7 D4+
8 D4-
