Interfaces
v800-Cabinet
Lenze • BA v200-C v800-.C • 1.1 75
6.1.5 Order of steps during commissioning
• 24 V device: insert cable for power supply with cable end sleeves into terminals and
connect earthing
• Connect cable for serial / parallel data transmission and fasten the plugs to the sockets
• Plug in all other required cables and secure against slipping out.
6.1.6 Check for operational readiness
Check the device for hidden damages caused by improper transport, incorrect
operation/storage conditions or improper use. If damages are found, immediately shut down
the device and protect it against unintentional start-up.
