Component replacement – v800-Cabinet
Replacing the BIOS battery
98
Lenze • BA v200-C v800-.C • 1.1
Proceed as follows:
• Press the battery (1) (with the positive pole facing upwards) into the drawer (2) until it
engages.
• Turn over the drawer (3) (negative pole now facing upwards) and then slide it into its
compartment until it engages (4).
1 2 3
