Technical data
Leuze electronic BPS 307i 87
all dimensions in mm
1 Clamping jaws for mounting on the BPS
2 Clamp profile for fastening to round or oval pipes ( 16 … 20 mm)
3 Rod holder, turnable 360 °
Figure 13.11: Dimensioned drawing BT 56 mounting device
all dimensions in mm
Figure 13.12: Dimensioned drawing BT 300-1 mounting device
1
2
3
