Levitronix PuraLev iF100SU User Manual

User Manual for PuraLev
®
iF100SU
www.levitronix.com
PL-4079-00, Rev00, DCO# 21-271
12
IPS Cable Power ICP-1.1 (for EasyConnect and Stand-Alone drivers)
IPS Cable Signal ICS-1.1 (for EasyConnect drivers)
IPS Cable Signal ICS-1.2 (for EasyConnect and Stand-Alone drivers)
IPS Cable Signal ICS-2.1 (for EasyConnect drivers)
IPS Cable Signal ICS-1.3 (for EasyConnect and Stand-Alone drivers)
IPS Cable Signal ICH-1.1 (for OEM driver)
Figure 14: Basic dimensions and specifications of standard cables
Cable
Jacket
Minimum Bending Radius
Permanent Installation
Minimum Bending Radius
Sometimes Moved
PVC
7x Cable OD
15 x Cable OD
Table 7: Specifications for min. bending radius of cables
Note: If not mentioned explicitly all the cables are not suited for constant dynamic bending and movement!
to AC/DC Supply
to driver DC supply
to driver fieldbus IN
to driver fieldbus OUT
to external interface
EasyConnect driver: to fieldbus
Screw type wire
connector
10
to external PLC
to EasyConnect driver PLC
Screw type wire
connector
Wire size: 0.5 mm
2
Wire size: 0.08 mm
2
Wire size: 0.08 mm
2
Wire size: 0.14 mm
2
8
to external interfaces
to OEM driver connector
to external interface
to PLC of Stand-Alone driver
Screw type wire
connector
Wire size: 0.08 mm
2
Wire size signals: 0.14 mm
2
Wire size power: 0.5 mm
2
to flow sensor
to driver flow sensor input
11
9a
9b
9c
