Levitronix PuraLev iF100SU User Manual

User Manual for PuraLev
®
iF100SU
www.levitronix.com
PL-4079-00, Rev00, DCO# 21-271
20
4.2 Electrical Installation of EasyConnect Model
4.2.1 Overview of Connections and Designations
Figure 20: Electrical connections to EasyConnect flow control driver IFD-100.5
Pin #
Pin
Name
Wire
Color
1
Description
Standard
Designation
2
Specifications
Typical Levels
Note
2
P +
red
+ 24 VDC
Power Supply
Voltage: 24 VDC ±10%
Power: 100 W
“P -“ shall be connected to earth
1
P -
black
Ground/Earth
3
NC
white
Not connected
--
Wire of compatible cables is cut.
Wire of compatible cables is cut.
Table 11: Power supply connector of EasyConnect driver
Note 1: Wire colors of compatible cables: ICP-1.1-xx. Note 2: Designations for standard firmware. For other firmware refer to relevant documentation.
Pin #
Pin
Name
Wire
Color
1
Description
Standard
Designation
Typical Levels
Note
3
GND
brown
Ground
--
--
--
black
shield
6
NC
pink-blue
Not connected
--
--
--
1
RS485+
white
RS485+
Fieldbus
Modbus protocol.
For remote control with other devices.
Usage of Levitronix
®
Service Software with a
RS485 to USB adaptor cable (see Table 4).
2
RS485-
yellow
RS485-
4
Internal
grey
Internal
Do not
connect.
--
Internal bus needed to connect pumps for serial
pumping.
5
Internal
red
Internal
Table 12: Fieldbus IN connector of EasyConnect driver
Note 1: Screw type connector pin out and wires of compatible cables: ICS-1.1-xx and ICS-1.2-xx.
Pin #
Pin
Name
Wire
Color
1
Description
Standard
Designation
Typical Levels
Note
3
GND
brown
Ground
Supply
Output
24VDC 10%, 200 mA
(Max. current is together with Pout of PLC
connector in Table 14)
For supply of external devices (displays etc.).
Internally protected.
black
shield
6
Pout
pink-blue
Output 24VDC
1
RS485+
white
RS485+
Fieldbus
Modbus RTU protocol.
For remote control with other devices.
Usage of Levitronix
®
Service Software with a
RS485 to USB adaptor cable (see Table 4).
Feed through for multi-pump arrays (for
example serial pumping or blending)
2
RS485-
yellow
RS485-
4
Internal
grey
Internal
Do not
connect.
--
Internal bus needed to connect pumps for serial
pumping.
5
Internal
red
Internal
Table 13: Fieldbus OUT connector of EasyConnect driver
Note 1: Screw type connector pin out and wires of compatible cables: ICS-1.1-xx and ICS-1.2-xx.
Power Supply
Connector
PLC Connector
Fieldbus IN
Fieldbus OUT
Flow Sensor
Connector
