LEYBOLD TURBOVAC i(X) User Manual

Description
20 300855170_002_C8 - 08/2021 - © Leybold
62
62
42,5
149,5
h
59
135
105
56,7 54
116
45°
45°
Ø 124
54
PURGE
G 1/8"
VENT
G 1/8"
M6
4x M8 - 14
48 V DC Stromanschlusskabel,
Länge 0,6 m inkl. Stecker
DN 25 KF
X
4x M5 - 8
X
Ø 26
Ø a
Ø 213
DN a h
160 ISO-K 180 255
160 CF 202,5 266
200 ISO-K 240 250,5
200 CF 254 261,3
Fig. 1.11 Dimensional drawings, dimensions in mm
116
62
62
186,5
118,5
h
59
135
65,6 63,3
117
54
PURGE
G 1/8"
VENT
G 1/8"
M6
4x M8 - 14
DN 25 KF
X
48 V DC Stromanschlusskabel,
Länge 0,6 m inkl. Stecker
Ø a
Ø 213
Ø 26
TURBOVAC 850 i and 950 i with optional interface
TURBOVAC 850 i and 950 i
48 V Power supply cable,
0.6 m long incl. plug
48 V Power supply cable,
0.6 m long incl. plug
