LEYBOLD TURBOVAC i(X) User Manual

Description
21300855170_002_C8 - 08/2021 - © Leybold
54
62
116
62
180,3
142,6
59
135
56,3 54,4
102
M6
DN 25 KF
X
X
PURGE
G 1/8"
VENT
G 1/8"
Ø a
Ø 213
45°
45°
Ø 124
4x M8 - 14
48 V DC Stromanschlusskabel,
Länge 0,6 m inkl. Stecker
4x M5 - 8
Ø 26
h
DN a h
160 ISO-K 180 255
160 CF 202,5 266
200 ISO-K 240 250,5
200 CF 254 261,3
Fig. 1.12 Dimensional drawings, dimensions in mm
TURBOVAC 850 iX and 950 iX
48 V Power supply cable,
0.6 m long incl. plug
