2233.. IInnppuutt sseelleecctt ((
CCoommmmaanndd:: xx
bb))
((MMaaiinn PPiiccttuurree IInnppuutt))
G To select input source for main picture.
Transmission
Data Structure
MSB LSB
0
[x][b][ ][Set ID][ ][Data][Cr]
0 0 0 0 0 0 0
External Input Input Number
Ack
[b][ ][Set ID][ ][OK/NG][Data][x]
External Input Data
0 0 0 1 Analogue
0000 DTV
0010 AV
0 1 0 0 Component
0 1 0 1 RGB-PC
1 0 0 1 HDMI/DTV-PC
Input Number Data
0 0 0 0 Input1
0 0 1 1 Input4
0 0 1 0 Input3
0 0 0 1 Input2
2222.. KKeeyy((CCoommmmaanndd:: mm cc))
G To send IR remote key code.
Transmission
Data Key code - Refer to page 104.
[m][c][ ][Set ID][ ][Data][Cr]
Ack
[c][ ][Set ID][ ][OK/NG][Data][x]
