INSTALLER SETTING
Menu hierarchy & Setting Explanation
Detailed
explanation
Available Setting
options (range)
Unit Default
SERVICE
Monitoring
Input
status
SG1
In this Service menu, the status of all
physical inputs are listed up
Remark : If the input signal is normal, “1”
is displayed, while there is no
signal, “0” is displayed.
0 / 1 - -
SG2 0 / 1 - -
CN-EXT 0 / 1 - -
Antifreeze shortkey 0 / 1 - -
Thermostat (Heating) 0 / 1 - -
Thermostat (Cooling) 0 / 1 - -
Thermostat (DHW) 0 / 1 - -
Output
status
A1 Main pump
In this Service menu, the status of all
physical outputs are listed up
Remark : Displays “1” if a signal is being
sent, and “0” if there is no signal.
0 / 1 - -
A2 External pump 0 / 1 - -
A3 Mix pump 0 / 1 - -
A4 Solar pump 0 / 1 - -
A5 DHW 3-way-valve DHW / Space - -
A6 Mixing valve (Open) 0 / 1 - -
A7 Mixing valve (Close) 0 / 1 - -
A12 Cooling 2-way-valve 0 / 1 - -
A15 DHW Re-circulation pump 0 / 1 - -
A8 Backup heater (Step 1) 0 / 1 - -
A9 backup heater (Step 2) 0 / 1 - -
A10 DHW Boost heater 0 / 1 - -
A11 External boiler 0 / 1 - -
