131
INSTALLER SETTING
ENGLISH
Menu hierarchy & Setting Explanation
Detailed
explanation
Available Setting
options (range)
Unit Default
CONNECTIVITY
Meter
Interface
Modbus address
- Not use : Meter interface is not connected
- B0 : Meter interface is connected
(address 1)
DIP SW_01M @ PENKTH000 = Off
- B1 : Meter interface is connected
(address 2)
DIP SW_01M @ PENKTH000 = On
Not use / B0 / B1 - Not use
Unit
Port 1: Pulse/kWh
Spec of wattmeter at Port 1
(Power consumption heat pump)
0.1 ~ 9999.9
pulse/k
Wh
0000.0
Port 2: Pulse/kWh
Spec of wattmeter at Port 2
(Power consumption backup heater)
0.1 ~ 9999.9
pulse/k
Wh
0000.0
Port 3: Pulse/kWh
Spec of wattmeter at Port 3
(Power consumption DHW boost heater)
0.1 ~ 9999.9
pulse/k
Wh
0000.0
Port 4: Pulse/kWh
Spec of heat meter at port 4
(Heat produced by heat pump + backup
heater)
0.1 ~ 9999.9
pulse/k
Wh
0000.0
Energy
state
Signal type
External devices such as Home Energy
Management Systems can be used to
influence the operation of the heat pump.
Either two 230V inputs are used to collect the
status or Modbus isn used (for instance when
connected to LG ESS).
O
Not use /
230V inputs / Modbus
- Not use
To Next Page
