46
INSTALLATION OF INDOOR UNIT
Step 4. Detach the Installation sheet. Screw bolts at the hole marks on the wall.
When screwing bolts, use M8 ~ M11 anchor bolts to secure hanging the indoor unit.
Step 5. Hang the indoor unit at the supporting plate.
NOTE
Self drilling screw can be used as alternatives of M8 ~ M11 anchor bolts. But M8 ~ M11 anchor
bolts are more preferred.
To Next Page
