Lightware MMX4x2 Series

 MMX4x2 series – User's Manual 120


INFO:  Serial (local and link) port numbering can be found in the  section.
INFO:  Only MMX4x2-HT200 model has TPS serial link.
Protocol Setting
Command and Response #protocol #rs232 #rs-232 #serial
ç <serial_port>.ControlProtocol=<ctrl_protocol>
æ <serial_port>.ControlProtocol=<ctrl_protocol>
Parameters
Parameter Parameter description  
<serial_port> Serial port number
P1, P2
<ctrl_protocol> RS-232 protocol mode
0

1

Example
ç 
æ 
BAUD Rate Setting
Command and Response
ç <serial_port>.Baudrate=<baudrate>
æ <serial_port>.Baudrate=<baudrate>
Parameters
Parameter Parameter description  
<serial_port> Serial port number
P1, P2
<baudrate> Baud rate value
0
4800
1
7200
2
9600
3
14400
4
19200
5
38400
6

7

Example
ç 
æ 
Stopbits Setting
Command and Response
ç <serial_port>.StopBits=<stopbit>
æ <serial_port>.StopBits=<stopbit>
Parameters
Parameter Parameter description  
<serial_port> Serial port number
P1, P2
<stopbit> Stopbit value
0
1
1

2
2
Example
ç 
æ 
Parity Setting
Command and Response
ç <serial_port>.Parity=<parity>
æ <serial_port>.Parity=<parity>
Parameters
Parameter Parameter description  
<serial_port> Serial port number
P1, P2
<parity> Parity value
0
no parity
1
odd
2
even
Example
ç 
æ 




