MMX4x2 series – User's Manual 96
Command and Response #portstatus
ç
æ <a_out1_state>;<a_out2_state>;<a_out3_state>
the next 2-byte-long HEX code showing the current state of the output port.
Parameters
See the previous section.
M 0 0 0 F
Unlocked,
Muted
0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1
Reserved Reserved Reserved Reserved Reserved Reserved
Signal
presents
Connected
Example
ç
æ
Command and Response
ç
æ <audio_in1>;<audio_in2>;<audio_in3>
Parameters
The <audio_in#> parameter means the audio input port number (A1-A3).
Example
ç
æ
A1 input port is connected to output1, A2 input port is connected to output 2 and output3 ports.
Switching Audio Input
Command and Response
ç <audio_in>:<audio_out>)
æ
Parameters
Parameter Parameter description Parameter values
<audio_in> Audio input port
A1-A3
For inputs
<audio_out> Audio output port
O1-O3
For outputs
Example
ç
æ
A2 port is connected to O1 port.
Command and Response #autoselect
ç
æ <out1_set>;<out2_set>;<out3_set>
The response shows the settings of each output one by one. The structure of the response is the following:
<out#_set> = <state><mode>
Parameters
Parameter Parameter description
<state> The state of the
autoselect
E
The autoselect is enabled
D
The aut oselect is disabled
<mode> The mode of the
autoselect
F
First
P
Priority detect mode: always the highest priority active video
input will be selected.
L
Last detect mode: always the last attached input is
switched to the output automatically.
Example
ç
æ
EL
other ports.
INFO: For more information about the Autoselect feature, see The Autoselect Feature section.
