Seat Depth Adjustment
 Pull the lever (3) upwards.
The seat surface can be moved to the desired
position by sliding the seat surface forwards or
backwards.
Seat Height Adjustment
Adjust the seat height as required.
 Push the lever (4) upwards to move the
seat upwards.
 Push the lever (4) downwards to move the
seat downwards.
Backrest Extension Adjustment
 Push the backrest extension (5) in or pull it
out for individual adjustment.
Lumbar Adjustment
NOTE
The lumbar support enables the seat backrest
contour to be optimally adapted to the driver's
body.
 Press the push button (6).
The extent to which the upper area of the
backrest is curved is adjusted individually.
 Press the push button (7).
The extent to which the lower area of the
backrest is curved is adjusted individually.
Seat Heating
If the seat is equipped with the optional tem-
perature control system, the switch (8) will not
be present. (See below.)
 Push the switch (8) upwards to activate the
seat heater.
 Push the switch (8) downwards to deacti-
vate the seat heater.
NOTE
The maximum temperature is predefined.
6
7
8
5
3
4
9
d12020014a

6
7
8
5
3
4
9
d12020014a

Operation
4
Operator Compartment
