4 | Description LINXON
18 / 90 LX218-Operating-Manual-en1-04-(1908)
• If a value is selected in the windows, you can modify the selected processing
position with the button on the left side.
• If multiple values are present in the row, press the button on the left side again.
• You can change selected values at the edit position using the "+" or "-" buttons. If
you hold down the "+" or "-" buttons, the values change continuously in ascending
or descending order.
• Save the changed values to activate them. Press the button next to "Save".
• Modified values that are not stored are not enabled.
• Press [Back] to return to the last menu.
• Press [Home] to return to the "Standby" window.
4.3.2.1 START button
• To start the measurements.
During evacuation, the LED flashes. During the measurement, the LED lights up
continuously.
4.3.2.2 STOP button
• To stop the measurements.
4.3.2.3 ZERO button
• To hide the "Background signal", see also "Definition of terms [}6]”.
To switch off the function ZERO again, press the buttonZERO for about 3 seconds.
The function ZERO should be activated only if the leak rate signal is stable and no
leak is measured. See also "Setting filter and ZERO [}45]".
4.3.2.4 Meaning of the function symbols
Adjust the volume for the speaker.
Adjust volume: The currently adjusted volume is displayed at the bottom edge
of the display.
The value range is 0 (off) to 15 (max.).
Call up the "Configuration" menu.
ZERO is active.
Call up the calibration.
