LINXON Operation | 6
LX218-Operating-Manual-en1-04-(1908) 37 / 90
6 Operation
6.1 Switching on
Before you switch on the device, connect the accessories or devices that are also
needed.
Operation mode Connected to
Operation mode "Sniffing" Sniffer line on vacuum chamber flange
Operation mode "Vacuum" Test object
►
In order to switch on the device, press the power switch.
ð When delivered, the device shows the window "Standby" after run-up.
6.2 Standby
After run-up, the "Standby" window is shown.
Certain parameters are displayed under the name "Standby".
Parameter Meaning Comments
Operation mode Operation mode Switch between operation
modes "Vacuum" and
"Sniffing"
Q
BG
Current background signal Appears if the
corresponding option in the
"Background ready to
start" menu has been
selected.
Mass Gas Switch between
4
He,
3
He,
H
2
Operation mode selection
1.
In the "Standby" window, select the "Select operation mode" menu.
2.
Select the operation mode "Measuring".
3.
Choose between "Vacuum" or "Sniffing".
ð The current operation mode is displayed in the "Standby" window.
4.
Select "Save".
