5 | Installation LINXON
36 / 90 LX218-Operating-Manual-en1-04-(1908)
1 Connection for the external pump
At the bottom of the device is the DN 25 ISO-KF connection flange. To install the
hose, proceed as follows:
1.
Lay the device on its side.
2.
Place an O-ring between the end of the hose and the connection flange.
3.
Clamp both together with a clamping ring.
4.
Raise the device up.
