Options Value range (min./max.) Comments
Deactivated Deactivated
0.01 - 0.5 mbar Pressure at which valve V4
opens
FINE Activated Activated
Deactivated Deactivated
0.1 - 0.5 mbar Pressure at which valve V3
opens
GROSS Activated Activated
Deactivated Deactivated
0.1 - 25 mbar Pressure at which valve V1
opens
6.4.4 Setting the evacuation time and ventilation
Standby > Configuration > Test settings > Evacuation time & ventilation
Note the following information for the "Evacuation time & ventilation" menu:
"Venting: Deactivated" or "Venting: Manual" prevents the unintentional venting of
vacuum devices connected to the inlet flange.
With the setting "Venting: Deactivated", the inlet flange can only be flooded by
changing the settings in the menu "Evacuation time & ventilation".
With the "Venting: Manual" setting, you can perform a targeted venting in the
"Standby" window by pressing the STOP button for more than 2 seconds.
Options Value range (min./max.) Comments
Maximum possible
evacuation time
1 s … 30 min., indefinite If the test object has a
gross leak, then the pump
down time will be longer.
The maximum evacuation
time limits the time that the
test object is evacuated.
If this time is exceeded, the
pump down operation
stops before reaching the
final pressure of 15 mbar
and an error message is
displayed.
Venting Manual The test connection can be
vented by pressing "Vent"
in the "Standby" window.
