6 | Operation LINXON
58 / 90 LX218-Operating-Manual-en1-04-(1908)
Settings
Run-up > Configuration > Information > Settings
The current settings for the device are listed in this menu. The settings can not be
changed here.
System data
Standby > Configuration > Information > System data
The system data for the device are listed in this menu. The information is divided up
as follows:
PUMPS
MASS SPECTROMETER
TEMPERATURE & PRESSURE
VARIOUS
SERIAL INTERFACE
DIGITAL INPUTS
DIGITAL OUTPUTS
Vacuum diagram
Standby > Configuration > Information > Vacuum diagram
The graphical representation of the measurement system shows the following:
the current switching state of the valves
the background value
the pressure of the backing pumps measured at the inlet of the backing pump (p1)
and at the inlet flange (p2) by the measuring devices.
Error list
Standby > Configuration > Information > Error list
The error list shows the last 12 reported errors.
For each error, the dates and the time, the number of the error message and a part of
a comment are displayed. One of the error messages is always selected. You can
move the selection up or down using the buttons next to the arrow symbols. You can
call up the complete message for the selected error message by pressing the
magnifying glass symbol. This contains the error description as well as information on
possible causes and corrective measures.
Calibration history
Standby > Configuration > Information > Calibration history
