Lippert Components In-Wall Slide-Out User Manual

Rev: 06.14.2016
Page 26
IN-WALL® Slide-out Service Manual
IN-WALL
®
SLIDE-OUT COMPONENTS
SLIDEOUTS
A
C
D
B
E
F
G
H
I
J
Callout Part # Description
A *See Note Upper Gear Rack
B *See Note Lower Gear Rack
C *See Note Lower Bearing Block
D *See Note Upper Bearing Block
E *See Note Lower Bearing Block (Hex Shaft)
F *See Note Upper Bearing Block (Hex Shaft)
G *See Note Lower Bearing Block (Inverted)
H *See Note Upper Bearing Block (Inverted)
I *See Note V-Roller
J *See Note Snap Ring
NOTE: *Parts shown for reference only. Parts are not
available for individual replacement. Repair kits
that include these components are available.
