5.4.4 Fresh water and waste water system
In LMC motorhomes, the fresh and waste water tanks are installed
under the floor and optionally can also be equipped with an
insulation box. A precise overview of the respective filling levels
can be obtained by querying the operating unit.
With the LMC Tourer, the valves are arranged in a decentralised
manner.
With the LMC Cruiser, the valves are arranged centrally on the left
side of the vehicle in the service compartment.
5.4.4.1 Fresh water tank
Fresh water filler neck
Fig. 93: Fresh water filler neck
The fresh water tank is filled via the fresh water filler neck. It is
located on the exterior side wall of the vehicle. All valves must be
closed prior to filling.
CAUTION
Risk of poisoning!
Only small drops of fuel can contaminate the fresh
water and cause severe health hazards.
• Never confuse the fuel tank lid with the fresh water
filler neck!
Filling level-pre-setting and draining of the fresh water tank are
possible directly at the tank via the combination drain valve. The
cleaning opening and the knurled screw of the combination drain
valve are accessible after removal of the floor flap.
