Operating manual and inspection booklet
Overview
3435216 75
5.1.12 LED switches and LED displays (optional)
Dependent on the vehicle equipment, there are, in addition to the operating and control panel, other LED
switches and LED displays, as shown in the overview:
Figure Description Display
ALDE - Turbo convector with 2 fans Yellow = operating
1 x green = fan at level I
2 x green = fan at level II
Engine preheating via
ALDE heat exchanger
Yellow = operating
1 x green = pump operating
Windscreen heating via multivent Yellow = operating
1 x green = fan at level I
2 x green = fan at level II
Switch for floor heating On/Off switch:
red = on
