Additional vehicle fuses
General
The arrangement of the individual plug-in locations depends on
the selected vehicle and equipment.
When changing the fuses, compliance with the operating
instructions of the base vehicle manufacturer is mandatory!
The following tables provide an overview on how the additional
pug-in fuses are arranged in the fuse distribution box.
Optional "Fiat" interface module under the driver's seat
Consumers on optional control module Ampere
Left side marker light 5
Right side marker light 5
Plug-in fuse locations next to the starter battery Ampere
Fuse for the booster/charger supply line 50
Fuse for the “Fiat” interface module 10
Plug-in fuse locations next to the living room battery Ampere
Fuse for the living room battery 50
Fuse for the booster supply line 10
Fuse for the battery sensor 2
For the “H” fuse lift-up bed control 20
