Operating manual and inspection booklet
Overview
116 3435216
ALDE drain valves
Fig. 95: ALDE drain valves
The following drain valves / outlet valves are installed behind the
service door at the left front of the vehicle:
1 Cold water drainage cock
2 Hot water drainage cock
3 Drain valve switch for waste water (grey water)
Red LED on = drain valve open
Red LED off = drain valve closed
