Operating manual and inspection booklet
Camping
118 3435216
Fig. 97: Fresh water intake port
1. Open the fresh water intake port.
– Hold the twist cap firmly with one hand, insert the
caravan body key into the lock and turn the key 180°.
– When the lock is unlocked, press the twist cap and turn
it 120° anticlockwise.
– Subsequently, remove the twist cap.
2. Prior to refilling, drain the remaining water from the fresh
water tank and thoroughly flush it.
3. Before using the filling holes ensure to to rinse it with 2 to 3
times the volume of the tank.
4. Insert the filling hose into water intake port and fill the tank
with fresh water.
NOTICE
The knurled thumb screw of the overflow valve must
be closed in order to utilise the full capacity of the
freshwater tank.
5. Thoroughly flush out all lines. To do this, first, open all drain
valves, ensure to rinse them thoroughly and closed the
valves again.
6. Turn on the water pump, turn the mixer tap first into the
warm water position, then open the cold water position,
rinse well and close again.
Fig. 98: Twist cap (left), fresh water intake
port (right)
7. After filling of the freshwater tank is completed, remove the
filling hose and close the freshwater intake port.
– Insert the twist cap with the pins in the grooves of the
fresh water intake port.
– Press the twist cap and turn it clockwise 120°.
– Turn the key in the lock 180° clockwise and withdraw
the key.
8. Finally, empty the filling hose and cap the ends.
