Operating manual and inspection booklet
Camping
126 3435216
Fig. 108: Gas pressure regulator set
Fig. 109: Supplied assembly/removal tool
6. Screw the union nut of the burst hose safety-valve (3) on to
the gas bottle valve using the supplied tool.
7. Inspect the gas hose at the gas bottle valve, at the pressure
regulator, and over the entire hose length: Do not use the
gas bottle if it leaks, is porous or damaged! The gas hose
must be replaced by specialised personnel.
8. At the rotary knob (13), set the function of the gas bottles;
for example turn the rotary knob fully to the left:
– left gas bottle = active bottle
– right gas bottle = reserve bottle
The colour display in the view window (14) shows the
current operating status:
- Green = Gas consumption from the active bottle
- Red = Gas consumption from the reserve bottle
9. To operate gas devices, open the gas bottle valves and
release the gas pressure regulator ( Releasing the gas
pressure regulator).
10. Close the gas bottle box and close the lock.
Releasing the gas pressure regulator
After each opening of the gas bottle valves, the gas pressure
regulator must again be enabled.
1. Open the gas bottle valve (if you use two bottles: open both
bottle valves).
2. In two-bottle operation: press and hold the safety valve of
the active bottle.
