Operating manual and inspection booklet
Camping
3435216 157
Fig. 163: Release lever
Concluding the pedestal table Primero Comfort
1. Activate and hold the release lever (1).
2. Slightly press onto the table top to push it downward.
Whether the pressure is applied.at the centre or along the
side of the tabletop is irrelevant.
3. Let go of the release lever (1).
4. Place the cushion onto the lowered tabletop.
NOTICE
To raise the tabletop again, simply activate the
release lever. An integrated pneumatic spring assists
during the lifting of the tabletop. The tabletop can be
locked into place at any height.
CAUTION
Risk of injuries due to movable parts!
Since there is virtually no load applied to the
pneumatic spring (inside the column), there is an
elevated risk of injury while raising tabletop.
• The release lever must only be activated if the
table is completely assembled and placed properly
onto the floor.
CAUTION
Excessive load will damage the tabletop!
If the cushion is not in place, and the lowered tabletop
is subjected to excessive load, the table may be
damaged.
• Load may only be applied to the lowered tabletop
(bed position) if the upholstery is in place.
• If the table is free-standing, the available
accessories (strut, stool) must be added as
support when the table is lowered.
