Fig. 30: Closed position
In the closed position (sash fastener position for driving) the sash
fastener is located on the inside of the clamping block.
Before driving, it must be ensured that all sash fasteners are in
the closed position (Fig. 30).
Only with locking of all sash fasteners is it ensured that the hinged
windows remain securely closed and that property damage and
personal injury are prevented during driving.
Domed hinged windows (panoramic windows)
In addition to flat hinged windows, vehicles can optionally also be
equipped with domed hinged windows, depending on the floor
plan.
With this type of window too, it is necessary that all the sash
fasteners are located in the closed position before starting a
journey (Fig. 30).
Fig. 31: Inside view of the domed hinged
window with five sash fasteners
Only with locking of all five sash fasteners (Fig. 31) is it ensured
that the domed hinged windows remain securely closed and that
property damage and personal injury are prevented during driving.
Prompt repair is necessary in the event of damage or
malfunctioning of the sash fasteners. Before continuing a journey,
contact a specialist workshop for immediate repair of the locking
mechanism.
