Operating manual and inspection booklet
Overview
90 3435216
Power circuits inside the motorhome The power supply of the motorhome is divided into the following
separate circuits.
Power
circuit
Allocation (elements depending on model)
Normal light Drain valve for non-freezing liquid
Power-operated entrance step
Ceiling light
Awning light
Lighting
circuit 1
Interior lighting and power outlets
Lighting
circuit 2
Interior lighting and power outlets
Consumer Refrigerator
Heater
Pump
When the supply battery is connected and switched on, the
normal light circuit is always activated. Only when activating the
disconnect switch on the charger unit, this light circuit will be
switched off.
The light circuits 1 and 2 are switched by activating the light
circuit ON/OFF switch on the operating unit. When leaving the
vehicle, is mandatory to switch off these light circuits.
In the 12 V refrigerator can only be operated while the vehicle
engine is running. When switching the engine off, a cut-off relay
prevents deep discharge of the supply battery.
