Operating Manual
- Page 25 -
Set GPIO
GPIO Configure
Double Table Switch
Select left/right table when programming
5.2 F2 Menu
Below is a list of functions, which are found under the F2 key (F2 Menu):
Function Description
Group Edit
Allows a function to be applied to a user-defined group of
memory addresses. Functions include copy, delete, move,
multiply line speed, multiply dispense times, apply X Offset,
apply Y Offset, apply Z Offset.
Expand Step & Repeat
Expands the memory address locations which would be
performed at a Step & Repeat instruction so individual
memory addresses of the repeated instructions can be edited.
Program Name
Allows the user to register a name for the current program
number.
Z-axis Limit (mm)
Sets the MAXIMUM Z-axis value (the lowest tip position).
Once the Z-axis limit is set, the robot will prevent the tip
from jogging below the set location.
Initial Output Port
Sets the status of the output signals when the machine is
initialized.
Utility Menu
Opens the Utility Menu. See 5.2.1 Utility Menu.
To Next Page
