Operating Manual
- Page 83 -
Z Clearance = 10 mm ABSOLUTE:
Please see SECTION 8: Sample Programs for an example of the Z Clearance instruction.
7.4.6 X/Y Move Speed
X/Y Move Speed sets default X and Y-axis movement speed as the tip moves between figures in a
program, such as from one dispense point to another or from the end of line dispensing to the next
start of line dispensing.
7.4.7 Z Move Speed
Z Move Speed sets default Z-axis movement speed as the tip moves between figures in a program,
such as from one dispense point to another or from the end of line dispensing to the next start of line
dispensing.
10 mm
Z = 0 mm
Z = 10 mm
