Operating Manual
- Page 41 -
7.1.3 Line Passing
Registers the current XYZ location as a Line Passing point. This is a location on the line where the
tip changes direction, such as at the corner on a rectangle.
Also use a Line passing point before and after an Arc Point instruction.
7.1.4 Circle
Registers a circle, where the circle’s center is at the current XYZ location. To register a circle, jog
the tip to the circle’s center and press ENTER, and then press the key 4 (for circle). The display will
prompt you to type the following data:
Diameter: Type the diameter of the circle and press ENTER.
Over Angle: (The value is from 1~360). After dispensing the circle, while going through an extra
part of the circle defined by the Over Angle, the dispenser will be turned OFF.
Z Lift: 1. Yes 2. No
Selection: If you want the Z-axis (tip) to lift while going through the Over Angle, you must
select 1. Otherwise: select 2.
The speed must be set in a previous memory address by registering a Line Speed instruction using
the F4 key.
Dispense delay times used at the start of the circle and at the end of the circle can be controlled by
registering a Line Dispense Setup instruction in a previous memory address. The Line Dispense
Setup instruction is registered by pressing the F4 key.
See also 7.4.1 Line Speed and 7.4.2 Line Dispense Setup.
The upward motion of the tip after dispensing can be controlled by registering a Dispense End
Setup instruction and / or a Z Clearance instruction in a previous memory address.
Dispense End Setup and Z Clearance instructions are registered using the F4 key.
See also 7.4.4 Dispense End Setup and 7.4.5 Z Clearance.
