5 USE OF THE WINDLASS
During the use of the anchor windlass, do not change directly from one direction to the other but wait until the anchor windlass
stops before manipulating the control into the opposite direction.
5.1 Lowering the anchor
Lowering of the anchor can be carried out through the electric control or by gravity:
5.1.1 Lowering the anchor electrically
1. Make sure that the clutch is tightened. Disengage all chain xing devices.
2. Activate the safety switch
3. Press the DOWN button from the control at your disposal. In this way, the lowering of the chain will be perfectly controllable and the
unwinding of the chain regular.
4. Once the chain is lowered, deactivate the safety switch.
5. Engage the chain xing devices.
