Lorex L114V251 User Manual

22
Using the Setup Menu
Motion Detection
Configure settings for motion sensitivity,
motion grid, and the motion alarm for channels
1~4.
Figure 13.0 Motion Detection Setup menu
To apply motion detection:
1. From the Setup Menu, select Motion
Detection and press
. The Motion
Detection Setup menu opens.
2. Select Channel, and press  to select
channels 1~4.
3. Select Sensitivity and press  to select
1~4, or Off (1=lowest sensitivity, 4=highest
sensitivity).
4. Select Alarm Duration and press  to
select 5, 10, 15, 20, 25, 30, CONT
(continuous), or Off.
Note: Alarm Duration enables a buzzer to
accompany motion detection. Set the time
(in seconds) for the buzzer to sound when
motion is detected on a selected camera.
5. Press until the Exit menu appears.
Select Save & Exit and press to
save your settings.
Note: Sensitivity and Alarm Duration must
be enabled in order to see the Alarm icon
when motion is detected on a selected
channel.
Motion Area
Motion Area allows you set the specific area of
the channel for motion detection. This can be
useful in both high traffic and static areas.
ATTENTION: The Motion Area can only be
set using the buttons on the front panel.
Figure 13.1 Motion Area
CH3
2008/11/20 10:32:30
Motion Area
(CH1, CH2, CH3, CH4) MOVE
(MUTE, SELECT) SET (MENU) EXIT
To configure the motion area:
1. From the Setup Menu, select Motion
Detection and press
. The Motion
Detection Setup menu opens.
2. Select Motion Area and press .
3. Press  to move the cursor to a
desired area. Press
to set the cursor.
4. Press  to apply the blue motion
area. When finished, press
to set.
5. Press until the Exit menu appears.
Select Save & Exit and press to
save your settings.
