Appendix 3: Using Listen-in Audio
Appendix 3: Using Listen-in Audio
Listen-in audio allows you to listen to, and record live audio on the system.
You can record one audio channel (mono) with an RCA (male) audio cable.
DVR
Figure 20.0 Audio connection diagram
LINE IN AUDIO /
AUDIO CAPABLE CAMERA
(not included)
AUDIO OUT /
SPEAKERS
(not included)
To enable listen-in audio:
1. Connect an RCA audio cable (male) from an audio capable camera to the AUDIO IN port on
the rear panel.
2. Connect an RCA audio out cable (male) to the AUDIO OUT port on the rear panel.
3. From the Setup Menu, select Audio and press . The Audio menu opens.
4. Select Record and press  to turn audio recording On.
5. Press until the Exit menu appears. Select Save & Exit and press to save your
settings.
