Appendix 1: System Specifications
Appendix 1: System Specifications
As our products are subject to continuous improvement, Lorex Technology Inc. and its
subsidiaries reserve the right to modify product design, specifications, and prices without notice
and without incurring any obligation.
E&OE
Description Specification
Video Format NTSC / PAL
Operating System RTOS
VGA Output VGA
Video Input 4 x BNC (1Vp-p 75 ohms)
Audio Input 1 x RCA line-in
Video Output 1 x BNC (Monitor Out)
Audio Output 1 x RCA line-out
Language Multi-language
Display Frame NTSC: 120 fps (4 x 30 fps)
PAL: 100 fps (4 x 25 fps)
Recording Frame NTSC: 60 fps max.
PAL: 50 fps max.
Recording
Resolution
NTSC: 640x224
PAL: 640x272
Display Resolution NTSC: 640x448
PAL: 640x544
Compression
Format
MJPEG
Normal: 12KB/frame; High: 15KB/frame; Highest: 20KB/frame
Hard Disk 3.5" SATA (1 TB max.)
Backup USB (front panel)
Power Supply 12V DC / 4 A (AC 100V~240V 50/60 Hz)
Dimensions
(WxDxH)
220 mm x 228 mm x 48 mm
8.66" x 8.99" x 1.89"
Weight 1.5 kg / 3.31 lbs
