Instruction Manual

LHV2000 Series

#LX400060; r.35927/36038; en-US

iii

Table of Contents

Default Chapter4
- Table of Contents4
1 Important Safeguards8
- General Precautions8
- Installation8
- Service10
- Use10
2 LHV2000 Series Features11
3 Getting Started (LHV2000 Series)12
4 Front Panel (LHV2000 Series)13
- Lhv2104 / Lhv2108 / Lhv211613
- Lhv221613
5 Rear Panel (LHV2000 Series)15
6 Basic Setup (LHV2000 Series)17
- Step 1: Connect the BNC Cameras17
- Step 2: Connect the Mouse17
- Step 3: Connect the Ethernet Cable17
- Step 4: Connect the Monitor18
- Step 5: Connect the Power Adapter and Power on the DVR18
- Step 6: Upgrade Firmware to Latest Version (if Available)18
- Step 7: Verify Camera Image19
- Step 8: Set the Time19
- Default System Password & Port Numbers19
  - FLIR Cloud19
- Quick Access to System Information20
- Connecting Cameras20
7 Mouse Control24
8 Remote Control25
- Setting the Remote Control Address26
9 Using the System27
- On-Screen Display27
- Using the Quick Menu28
- Adjusting Color Settings28
- Using the Navigation Bar29
- Using the Camera Toolbar30
- Using the Virtual Keyboard31
10 Setting the Time32
11 Recording33
- Video Recording Types33
- Main Stream and Sub Stream33
- Setting up Scheduled or Manual Recording33
- Configuring Hard Drive Overwrite34
12 Search (Playback)36
- Playing Back Video from the Hard Drive36
- Playback Controls37
- Playing Back from a USB Drive37
- Using Smart Search38
13 Backup40
- Formatting the USB Thumb Drive40
- Backing up Video41
- Using Video Clip Backup42
- Viewing Backup Files43
14 Managing Passwords and User Accounts49
- Changing Passwords49
- Adding Users50
- Modifying Users51
- Deleting Users51
- Account Groups52
- Adding Groups52
- Modifying Groups53
- Deleting Groups53
15 Using the Main Menu54
- Camera54
- Info59
- Setting64
- Shutdown84
16 Connecting to Your System over the Internet on PC or Mac85
- System Requirements85
- Step 1 of 3: Connect Your System to Your Router85
- Step 2 of 3: Obtain the System's Device ID86
- Step 3 of 3: Connect to the System over the Internet86
17 Using FLIR Cloud™ Client for PC or Mac90
- Home Page90
- Live View90
  - Live View Controls91
  - Opening Live View in Multiple Monitors92
- Controlling PTZ Cameras93
- Playback97
- Playback Controls99
- Downloading Video to Your Computer Hard Drive100
- Alarm101
- Log102
- E-Map103
- Devices105
- Device Config106
- Alarm CFG106
- Tour & Task109
- Account110
  - Managing User Accounts110
  - Managing Roles112
- General113
18 Connecting to Your System Using Smartphone or Tablet Apps116
- FLIR Cloud116
- FLIR Secure156
19 DDNS Setup (Advanced)177
- Accessing Your System Within a Local Network (LAN)177
- DDNS Setup-Access Your System Remotely over the Internet180
20 LHV2000 Series Hard Drive Installation189
- Installing a Hard Drive189
  - Lhv2216189
  - Lhv2104 / Lhv2108 / Lhv2116191
- Removing the Hard Drive192
  - Lhv2216192
- Formatting Hard Drives194
- Connecting a Ptz Camera195
21 Connecting a PTZ Camera (LHV2000 Series)196
- Controlling a PTZ Camera (Local DVR)196
- Advanced PTZ Controls197
- Step 1 of 2: Connecting a Self-Powered Microphone201
- Step 2 of 2: Configuring Audio Recording201
22 Recording Audio202
23 Troubleshooting204
24 LHV2000 Series System Specifications206
25 Notices208
- Modification208
- Rohs208
- FCC/IC Notice209
